• Chrome front bumper w/Matte Black cover
• Chrome rear step bumper w/step pad
• Dark argent air dam
• Body-side molding w/bright trim
• Deluxe chrome grille
• Dual auto composite halogen headlamps
• Daytime running lamps
• Dual cargo area lamps
• Dual chrome fold away pwr mirrors
• Solar-Ray tinted glass
• Swing-out rear door windows
• Intermittent windshield wiper system
• Dual rear access doors hinged to rear of cab
• Removable tailgate w/badge name/decal
• Insulation-inc: cab, acoustic, thermal panel

• LS decor
• 3-passenger custom cloth 40/20/40 reclining front split bench seat w/center fold-down storage armrest, manual driver/passenger lumbar, adjustable outboard head restraints, front seatback storage pockets
• 3-passenger folding rear bench seat w/matching trim
• Color-keyed full-floor carpeting w/front/rear rubber floor mats
• Leather-wrapped steering wheel
• Tilt steering wheel
• Passlock II theft deterrent security system
• Driver message center warnings-inc: trans overheat, low fuel, low coolant, vehicle security, oil level/pressure/change needed
• Warning tones-inc: key-in ignition, seat belt, headlamp-on, turn signal
• Cruise control
• Auto programmable pwr door locks-inc: auto lock at 15 mph, backlit switches
• Pwr windows w/backlit switches
• Remote keyless entry-inc: 2-transmitters, panic button, content theft alarm
• Illuminated entry
• Air conditioning
• Rear passenger heat ducts
• ETR AM/FM stereo w/compact disc-inc: seek-scan, digital clock, auto tone control, theft lock, speed compensated volume, 6 speakers
• Dual seat-mounted cup holders
• Dual rear cup holders
• Dual covered pwr outlets
• Color-keyed soft vinyl door trim panels w/cloth inserts-inc: map pockets w/carpeted trim, door reflectors
• Mini overhead console w/map lights
• Color-keyed cloth headliner w/matching retainer moldings
• Dual color-keyed padded cloth sunshades w/driver storage clip, passenger mirror
• Passenger assist handles
• Lighting-inc: dome w/delayed entry feature, ashtray, glove box, underhood
• Dual coat hooks

• 4-wheel anti-lock brake system
• Driver & front passenger airbags w/passenger side deactivation switch
• Manual lap/shoulder safety belts, front/rear outboard seat positions
• Manual lap safety belts, center seat positions
• Head restraints at outboard seating positions
• Daytime running lamps
• Side door guard beams
• High/low note horn

4.8L (293) SFI V8 (VORTEC) ENGINE

• (STD)

• Mileage
• EPA Fuel Economy Est - City (MPG): 15
• EPA Fuel Economy Est - Hwy (MPG): 18
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 14.5
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 3750
• Curb Weight - Front (lbs): 2854
• Curb Weight - Rear (lbs): 1922
• Gross Vehicle Weight Rating Cap (lbs): 6400
• Gross Combined Wt Rating (lbs): 10,000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 600
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 500
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 750
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 3750
• Axle Type - Front: Hypoid
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3925
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 32
• Shock Absorber Diameter - Rear (mm): 32
• Stabilizer Bar Diameter - Front (in): 1.13
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 12.6 x 0.79
• Tires
• Front Tire Order Code: QNK
• Rear Tire Order Code: QNK
• Spare Tire Order Code: QNK
• Front Tire Size: P245/75R16
• Rear Tire Size: P245/75R16
• Spare Tire Size: P245/75R16
• Front Tire Capacity (lbs): 2064
• Rear Tire Capacity (lbs): 2064
• Spare Tire Capacity (lbs): 2064
• Revolutions/Mile @ 45 mph - Front: 682
• Revolutions/Mile @ 45 mph - Rear: 682
• Revolutions/Mile @ 45 mph - Spare: 682
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Chrome
• Rear Wheel Material: Chrome
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 14.0
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 47.3
• Turning Diameter - Wall to Wall (ft): 48.4
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 143.5
• Length, Overall w/o rear bumper (in): 227.6
• Width, Max w/o mirrors (in): 78.5
• Height, Overall (in): 73.9
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 47.0
• Front Bumper to Back of Cab (in): 138.7
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): 78.7
• Ground to Top of Load Floor (in): 32.9
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): 42.0
• Ground Clearance, Front (in): 8.9
• Ground Clearance, Rear (in): 8.7
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 60.2
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 60.6
• Cargo Volume (ft³): 56.9
• Ext'd Cab Cargo Volume (ft³): 49.7
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: Chevrolet Silverado 1500
• Body Style: Ext Cab 6.5' Fleetside
• Body Code: E63
